API 5l Gr X65 PSL 2 Carbon Steel Pipe
Products Description The composition of API 5L X65 seamless steel pipe includes carbon, manganese, phosphorus, sulfur, vanadium, niobium and titanium. This material has a minimum yield strength of 65ksi and a minimum tensile strength of 77ksi. Seamless and LSAW steel pipe are available in sizes...
Gnee Steel (Tianjin) Co., Ltd. is one of the most reliable manufacturers and suppliers of api 5l gr x65 psl 2 carbon steel pipe in China, also supports customized service with low price. Welcome to wholesale discount api 5l gr x65 psl 2 carbon steel pipe for sale here from our factory. Contact us for free sample.
Products Description
The composition of API 5L X65 seamless steel pipe includes carbon, manganese, phosphorus, sulfur, vanadium, niobium and titanium. This material has a minimum yield strength of 65ksi and a minimum tensile strength of 77ksi. Seamless and LSAW steel pipe are available in sizes from ½ inch to 48 inches. Welded and LSAW pipes are available in diameters up to 100 inches and lengths up to 12 meters. With wall thicknesses up to 250 mm, API 5l X65 PSL2 steel pipes are available in sizes from sch 20 to XXS. This material can be subjected to impact tests and other tests.
API 5L X65 PSL2 Specification Standard
| Standard | 5L grade X65 |
|---|---|
| Product Specification Level | 5L Product Specification Level 2 5L Product Specification Level 1 |
| Sizes | Np Size 1/2" to Sizes 48 upto Other Daimeter. WT - Sch 10 to 160, XS, STD, XXS. |
| Service |
Sand Blasting ARO Tar Epoxy Annealed Galvanizing 3LPE Machining etc. Bending Heat Treatment |
| Type | ERW /Seamless / Fabricated / Welded / CDW |
| Other stockist | JSL, MSL,ISMT, BAO, USL, Lontrin, TNRS, SMTM, and Wuxi |
| Applications | Petrochemicals, Oil Refineries, Pressure Vessels, Power Generation, Sugar, Steel, Boiler Equipments |
| Test Methods |
Hydrostatic test Flattening test DWT test for PSL2 pipe CVN impact test for PSL2 pipe (including pipe body tests, pipe weld and HAZ tests) Guided-bend test Bend test |
| Length | Double Random, Single Random, Any Sizes - 12 Meters |
| End | Screwed, Bevel, Plain, Threaded |
| Thickness | Schedule 40, 80, 160, XS, XXS |
API 5L PSL 2 Grade X65 Carbon Steel Pipes Chemical Composition
| Cb | L450Q or X65Q | L450M OR X65M |
| 0.18f | 0.12f | |
| Si | 0.45f | 0.45f |
| Mnb | 1.7f | 1.6f |
| P | 0.025 | 0.025 |
| S | 0.015 | 0.015 |
| V | g | g |
| Nb | g | g |
| Ti | g | g |
| Other | h | h |
| CEIIW | 0.43 | 0.43 |
| CEPcm | 0.25 | 0.25 |
Mechanical Properties of API 5L PSL 2 Grade X65 Carbon Steel Pipes
| Y.S | Mpa(psi) | min | 450(65 300) |
| T.S | Mpa(psi) | min | 600(87 000) |
| ELONGATION | min | 23% | |
