ASTM A210 Grade A1 Carbon Steel Tube
A210 is a standard specification for carbon steel boiler and superheat exchanger tubes. It offers a range of advantages and features for use in high temperature and high pressure environments.
Gnee Steel (Tianjin) Co., Ltd. is one of the most reliable manufacturers and suppliers of astm a210 grade a1 carbon steel tube in China, also supports customized service with low price. Welcome to wholesale discount astm a210 grade a1 carbon steel tube for sale here from our factory. Contact us for free sample.
ASTM A210 Grade A1 Carbon Steel Tube
There are three main types of ASTM A210 grade boiler tubes: seamless steel tubes, electrofusion welded (EFW) tubes, and double-sided submerged arc welded (DSAW) tubes.
ASTM A210 Seamless Steel Pipe offers superior strength and durability because it has no seams or welds. During the manufacturing process, seamless steel pipes are formed through extrusion, perforation, rolling and other processes. It is a high-quality pipe with high fatigue resistance and corrosion resistance, and is usually used in high-pressure and high-temperature applications.
ASTM A210 Electrofusion Welded (EFW) pipe manufacturing uses an electrofusion welding process to fuse the edges of two steel plates or steel pipes together. EFW is a single-pass welding process that is simple and efficient, but the strength of the weld may be reduced.
ASTM A210 double-sided submerged arc welded (DSAW) pipe manufacturing uses a submerged arc welding process that welds on both sides of the pipe. This process requires multiple passes of welding to complete, but provides greater strength and durability.
A210 A1 grade boiler tube, which is a carbon steel material whose main components include carbon, manganese, phosphorus, sulfur and silicon. The levels of these elements will vary depending on the manufacturing process and specific requirements. However, typically A210 Class A1 boiler tubes have a maximum carbon content of 0.27%, a maximum manganese content of 0.93%, and a maximum sulfur content of 0.025%. These components also determine the physical and mechanical properties of the pipe.
Product Properties
Chemical Composition Of ASTM A210 Grade A1
| Standard | Grade | chemical composition: | ||||
| C（a） | Si | Mn | P | S | ||
| ASTM A210 | A-1 | ≤0.27 | ≥0.10 | ≤0.93 | ≤0.035 | ≤0.035 |
Mechanical Properties Of ASTM A210 Grade A1
| Mechanical Properties | Grade A-1 |
| Tensile strength, min, ksi [MPa] | 60 [415] |
| Yield strength, min, ksi [MPa] | 37 [255] |
| Elongation % | 30 |
| HRB | 79 |
| HB | 143 |
Note:Mechanical property requirements do not apply to tubing smaller than 1/8 in.
Tolerances of Wall Thickness
| Outside Diameter, in. [mm] |
Wall Thickness, % | |||||||
| 0.095[2.4] and Under | Over 0.095 to 0.150 [2.4 to 3.8], incl |
Over 0.150 to 0.180 [3.8 to 4.6], incl |
Over 0.180,[4.6] | |||||
| Over | Under | Over | Under | Over | Under | Over | Under | |
| Seamless, Hot-Finished Tubes | ||||||||
| 4 [101.6] and under | 40 | 0 | 35 | 0 | 33 | 0 | 28 | 0 |
| Over4 [101.6] | .... | .... | 35 | 0 | 33 | 0 | 28 | 0 |
| Seamless, Cold-Finished Tubes | ||||||||
| Over | Under | |||||||
| 1 1 ⁄ 2 [38.1] and under | 20 | 0 | ||||||
| Over 1 1 ⁄ 2 [38.1] | 22 | 0 | ||||||
Tolerances of Outside Diameter
| Outside Diameter,in. [mm] | Permissible Variations, in. [mm] | |
| Over | Under | |
| Hot-Finished Seamless Tubes | ||
| 4 [101.6] and under | 1 ⁄ 64 [0.4] | 1 ⁄ 32 [0.8] |
| Over 4 to 7 1 ⁄ 2 [101.6 to 190.5], incl | 1 ⁄ 64 [0.4] | 3 ⁄ 64 [1.2] |
| Over 7 1 ⁄ 2 to 9 [190.5 to 228.6], incl | 1 ⁄ 64 [0.4] | 1 ⁄ 16 [1.6] |
| Cold-Finished Seamless Tubes | ||
| Under 1 [25.4] | 0.004 [0.1] | 0.004 [0.1] |
| 1 to 1 1 ⁄ 2 [25.4 to 38.1], incl | 0.006 [0.15] | 0.006 [0.15] |
| Over 1 1 ⁄ 2 to 2 [38.1 to 50.8], excl | 0.008 [0.2] | 0.008 [0.2] |
| 2 to 2 1 ⁄ 2 [50.8 to 63.5], excl | 0.010 [0.25] | 0.010 [0.25] |
| 2 1 ⁄ 2 to 3 [63.5 to 76.2], excl | 0.012 [0.3] | 0.012 [0.3] |
| 3 to 4 [76.2 to 101.6], incl | 0.015 [0.38] | 0.015 [0.38] |
| Over 4 to 7 1 ⁄ 2 [101.6 to 190.5], incl | 0.015 [0.38] | 0.025 [0.64] |
| Over 7 1 ⁄ 2 to 9 [190.5 to 228.6], incl | 0.015 [0.38] | 0.045 [1.14] |
Suppliers of ASTM A210 Grade A1 Carbon Steel Tube
The packaging of carbon steel pipes varies according to different requirements.
Woven bag packaging. Put the carbon steel pipe into a woven bag, then bundle and seal it to prevent the steel pipe from being damaged during transportation.
Wooden frame packaging. Make a wooden frame with wooden strips and wooden boards around the periphery of the carbon steel pipe, and then put the carbon steel pipe into it to prevent the steel pipe from being hit and squeezed during transportation.
Carton. Place the carbon steel pipes into cartons, then seal and bundle them to prevent the steel pipes from being damaged during transportation.
Bulk. Some carbon steel pipes with shorter lengths can be stacked directly on the transportation vehicle without special packaging.
FAQ
Q.How can I place order?
A: You can contact us by email about your order details, or place order on line.
Q.Do you provide custom made Products service?
A: Yes if you have your own design , we can produce according to your specification and drawing.
Q.How do you guarantee the quality of your products?
A.Each product is produced by certified workshops and inspected piece by piece in accordance with national QA/QC standards, we can also issue quality assurance certificates to our customers.
Q.What is a 210 A1 material?
A.SA210A1 is a Seamless medium carbon steel Boiler Tube used in super heater, heat exchangers, condensers, marine application.
